PLAN 20-320
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 45'
Height : 34'
Width : 76'
Area
First Floor: 1758 sq/ft
Garage: 694 sq/ft
Porch: 258 sq/ft
Second Floor: 1380 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Wood - 2x4
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Rear Porch
Rooms
Bathroom 2:
29 sq/ft width 5' 4" x depth 5' 6"
Bathroom 3:
52 sq/ft width 10' 6" x depth 5'
Bathroom 4:
57 sq/ft width 11' 6" x depth 5'
Bedroom 2:
164 sq/ft width 14' 4" x depth 11' 6"
Bedroom 3:
149 sq/ft width 13' x depth 11' 6"
Bedroom 4:
126 sq/ft width 11' x depth 11' 6"
Dining Room:
250 sq/ft width 14' 4" x depth 17' 6"
Family Room:
370 sq/ft width 19' x depth 19' 6"
Foyer:
156 sq/ft width 12' x depth 13'
Garage:
625 sq/ft width 21' 4" x depth 29' 4"
Kitchen:
164 sq/ft width 11' 4" x depth 14' 6"
Kitchen Island:
15 sq/ft width 5' x depth 3'
Living Room:
250 sq/ft width 14' 4" x depth 17' 6"
Master Bathroom:
117 sq/ft width 10' 4" x depth 11' 4"
Master Bedroom:
250 sq/ft width 14' 4" x depth 17' 6"
Master Closet:
72 sq/ft width 9' x depth 8'
Nook:
126 sq/ft width 11' 6" x depth 11'
Utility Room:
48 sq/ft width 6' x depth 8'
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
Plan Set
$956.25
$1207.00
Foundation
$0.00
$165.75
$165.75
Framing
$0.00
$165.75
Additional Options
$165.75
$140.25
$335.75
$33.15
$140.25
