PLAN 47-712
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 30'
Height : 21'
Width : 44'
Area
Basement Unfinished: 1130 sq/ft
First Floor: 1194 sq/ft height 8'
Roof
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Rooms
3rd BR Closet:
7 sq/ft width 3' 6" x depth 2'
Basement Foundation:
1070 sq/ft width 44' x depth 24' 4"
Bedroom 2:
101 sq/ft width 9' 4" x depth 10' 11"
Bedroom 2 Closet:
11 sq/ft width 5' 10" x depth 2'
Bedroom 3:
90 sq/ft width 9' 4" x depth 9' 9"
Bedroom 3 Closet:
11 sq/ft width 5' 10" x depth 2'
Deck:
172 sq/ft width 21' 6" x depth 8'
Dining Room:
89 sq/ft width 8' 7" x depth 10' 5"
Foyer:
26 sq/ft width 7' 4" x depth 3' 8"
Hall Bathroom:
35 sq/ft width 7' 2" x depth 5'
Hall Closet:
7 sq/ft width 3' 6" x depth 2'
Kitchen:
140 sq/ft width 14' x depth 10'
Living Room:
249 sq/ft width 16' x depth 15' 7"
Master Bathroom:
53 sq/ft width 7' 2" x depth 7' 6"
Master Bedroom:
132 sq/ft width 12' x depth 11' 1"
Master Closet:
11 sq/ft width 5' 10" x depth 2'
Porch - Front:
28 sq/ft width 7' x depth 4'
