Plan Description
This three bedroom home is perfect for a narrow lot. The master bedroom has a
large walk-in closet and full private bath with a double vanity. There are two
additional bedrooms; one of them is an optional den with a cathedral ceiling.
The great room fireplace provides a warm focal point, especially with the
windows on each side. A main floor laundry is located just outside the garage
for quick clean-ups. This kitchen has a large island for additional counter
space. The dining room is located right off the kitchen, which gives this area
a sense of greatness.
Floor Plans
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 45'
Height : 25'
Width : 54' 8"
Area
First Floor: 1600 sq/ft height 8'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Bedroom Features
Fireplace
Additional Room Features
Great Room Living Room
Outdoor Spaces
Deck
Rooms
Bedroom 2:
117 sq/ft width 10' 8" x depth 11'
Den/Office or Bedroom 3:
130 sq/ft width 11' x depth 11' 10"
Dining Room:
120 sq/ft width 10' x depth 12'
Garage:
406 sq/ft width 20' 8" x depth 19' 8"
Great Room:
256 sq/ft width 14' x depth 18' 4"
Kitchen:
116 sq/ft width 10' x depth 11' 8"
Master Bedroom:
185 sq/ft width 14' 8" x depth 12' 8"
Wood Deck:
117 sq/ft width 9' 10" x depth 12'
