PLAN 20-1609
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 65' 8"
Height : 24'
Width : 50'
Area
First Floor: 1905 sq/ft height 9'
Garage: 561 sq/ft
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 6:12
Roof Framing : Combination Truss/Conventional
Roof Type : Asphalt
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : 2"x6"
Rooms
Breakfast:
132 sq/ft width 12' x depth 11'
Entry:
99 sq/ft width 6' 4" x depth 15' 8"
Flex Room:
121 sq/ft width 11' x depth 11'
Great Room:
277 sq/ft width 18' 6" x depth 15'
Kitchen:
156 sq/ft width 12' x depth 13'
Kitchen Island:
33 sq/ft width 11' 4" x depth 3'
Laundry Room:
87 sq/ft width 9' 8" x depth 9'
Master Bathroom:
118 sq/ft width 10' 5" x depth 11' 4"
Master Bedroom:
302 sq/ft width 14' x depth 21' 7"
Master Closet:
72 sq/ft width 8' x depth 9'
What's Included In This Plan Set
- Cover Page: Front elevation and informative reference sections including: general notes and design criteria
- Elevations: Drafted at 1/4" scale for the front and 1/8" scale for the rear and sides. All elevations are noted and an aerial view of the roof is provided, showing all hips, valleys and ridges.
- Foundation: Drafted at 1/4" scale. Poured or block basement or slab foundations are standard. Shows the HVAC equipment, structural information, steel beam and pole locations and the direction and spacing of the floor system above. Alternate foundations are available for a fee.
- Main Level Floor Plan: 1/4" scale. Fully dimensioned from stud to stud for ease of framing. The detailed drawings include such things as structural header locations, framing layout and kitchen layout.
- Second Level Floor Plan: 1/4" scale. Dimensioned from stud to stud and drafted to the same degree of detail as the main level floor plan.
- Elevations: Useful for the cabinet and bidding process, this page shows all kitchen and bathroom cabinets as well as any other cabinet elevations. Not included with all plans, please call for details.
- Electrical and Sections: Illustrated on a separate page for clarity, the electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall and stair sections are provided to further explain construction of these areas.
Plan Set
$1105.00
$1605.00
$1790.00
$2290.00
Foundation
$0.00
$295.00
$295.00
$390.00
Framing
$0.00
$295.00
Additional Options
$295.00
$250.00
$165.00
$39.00
$165.00
$195.00
$500.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
