PLAN 1057-19

Home > Style > Craftsman

Key Specs

3164
sq ft

4
Beds

3.5
Baths

2
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Modify This Plan

Plan Description

This narrow lot Farmhouse design is packed with great living space. The main floor is open for allowing great entraining and socializing. The home is equipped with a large working panty with a swing up window for entertaining out the covered porch. The upper level contains 4 bedrooms with 3 baths. The master suite with large duel closets. Every bedroom has a step up ceiling making each room feel even larger. Great home for the small lake lot with a sloping grade.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Full Specs & Features

Dimension

Depth : 65' 10"

Height : 38'

Width : 40' 6"

Area

Basement : 1213 sq/ft

Decks : 332 sq/ft

Garage : 490 sq/ft

Main Floor : 1316 sq/ft

Porch : 400 sq/ft

Storage : 415 sq/ft

Upper Floor : 1848 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Tray and step ceilings on all bedrooms

Garage Ceiling : 10' 6"

Lower Ceiling : 10'

Main Ceiling : 9'

Upper Ceiling Ft : 8'

Roof

Primary Pitch : 7.5/12

Roof Framing : wood

Roof Type : trusses

Secondary Pitch : 12/12

Exterior Wall Framing

Exterior Wall Finish : Board and batten, horizontal siding and stone veneer

Framing : 2x6 wood

Insulation : 21

Bedroom Features

Upstairs Bedrooms

Upstairs Master Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Mud Room

Storage Area

Unfinished Future Space

Upstairs Laundry

Garage Features

Front Entry Garage

Lot Characteristics

Suited For Narrow Lot

Suited For Sloping Lot

Suited For View Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Jack & Jill Bath

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.

Questions? Call 1-877-222-1762

Plan Set

PDF Set:
$1680.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Set:
$1920.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

PDF Unlimited Build:
$6400.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Unlimited Build:
$7200.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Walk Out Basement:
$0.00

Ideal for a sloping lot, lower level with outdoor access.

Basement:
$400.00

Ideal for level lot, lower level of home partially or fully underground.

Crawlspace:
$400.00

Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Daylight Basement:
$400.00

Ideal for sloping lot, lower level of home partially underground.

Slab:
$400.00

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x6:
$0.00

Wood 2x6 Exterior Walls

Wood 2x4:
$400.00

Wood 2x4 Exterior Walls

Additional Options

Right-Reading Reverse:
$400.00

Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Use License:
$960.00

Allows you to build one more home for each additional license purchased.

Audio Video Design:
$80.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$31.20

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
