Key Specs
3527
sq ft
4
Beds
2.5
Baths
2
Floors
4
Garages
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 70-503
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 63' 4"
Height : 32'
Width : 91' 4"
Area
First Floor: 2260 sq/ft
Second Floor: 1050 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Stone
Framing : 2"x6"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Loft
Storage Area
Sunroom
Workshop
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Balcony
Covered Front Porch
Screened Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
156 sq/ft width 12' x depth 13'
Bedroom 3:
169 sq/ft width 13' x depth 13'
Bedroom 4:
164 sq/ft width 12' 4" x depth 13' 4"
Dining Room:
239 sq/ft width 14' 6" x depth 16' 6"
Great Room:
379 sq/ft width 18' 8" x depth 20' 4"
Kitchen:
325 sq/ft width 22' 4" x depth 14' 7"
Master Bedroom:
219 sq/ft width 14' x depth 15' 8"
Sun Room:
200 sq/ft width 14' 8" x depth 13' 8"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$1349.80
$1409.30
$1739.10
$1739.10
$2788.85
Foundation
$0.00
$335.75
$335.75
Additional Options
$335.75
$68.00
$85.00
$335.75
$33.15
$63.75
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
