Key Specs
3942
sq ft
3
Beds
3.5
Baths
2
Floors
3
Garages
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 40-492
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 69' 6"
Height : 33' 9"
Width : 77'
Area
First Floor: 2367 sq/ft height 10'
Garage: 902 sq/ft height 10'
Porch: 425 sq/ft
Second Floor: 1575 sq/ft height 9'
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Brick/Stone
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Guest Suite
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Master Sitting Area
Workshop
Garage Features
Side Entry Garage
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
Deck
Rooms
Bedroom 2:
232 sq/ft width 11' 11" x depth 19' 6"
Bedroom 3:
225 sq/ft width 13' 10" x depth 16' 4"
Breakfast Nook:
119 sq/ft width 11' 11" x depth 10'
Dining Room:
154 sq/ft width 11' x depth 14'
Game Room:
339 sq/ft width 20' 3" x depth 16' 9"
Garage:
769 sq/ft width 23' 4" x depth 33'
Kitchen:
196 sq/ft width 14' x depth 14'
Living Room:
391 sq/ft width 23' 10" x depth 16' 5"
Master Bedroom:
268 sq/ft width 13' 10" x depth 19' 5"
Sewing Room:
154 sq/ft width 11' x depth 14'
Study:
154 sq/ft width 11' x depth 14'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$945.00
$995.00
$1045.00
$1145.00
$1645.00
$850.00
Foundation
$0.00
$0.00
Framing
$0.00
Additional Options
$175.00
$60.00
$100.00
$39.00
$200.00
$55.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
