PLAN 140-149

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Modify This Plan

Plan Description


It's all about sweeping views with this ranch plan. The central part of the home celebrates a beautiful vista with windows and porch access. Actually, just about every room steps out to the porch, so you can get outside and be inspired by the sunset.

Full Specs & Features


Dimension

Depth : 54'

Height : 26'

Width : 126'

Area

Bonus : 299 sq/ft

Main Floor : 2693 sq/ft

Porch : 2424 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 10:12

Roof Framing : trussed

Secondary Pitch : 2:12

Exterior Wall Framing

Exterior Wall Finish : stone

Framing : 2"X6"

Bedroom Features

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Additional Room Features

Den Office Study Computer

Main Floor Laundry

Mud Room

Sunroom

Lot Characteristics

Suited For Corner Lot

Suited For View Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Screened Porch

Wrap Around Porch

More

Jack & Jill Bath

What's Included In This Plan Set


  • Cover page
  • Elevations set to 1/4" scale
  • Dimensioned Floor plans set to 1/4" scale
  • Roof plan: Overhead plan shows peaks, valleys and roof pitch
  • Building Sections Interior Elevations: Cabinet and millwork details.
  • Electrical floor plan layout
  • Foundation plan
  • General notes and details.
» See important information before purchasing.
Questions? Call 1-877-222-1762

Plan Set

5 Copy Set:
$573.75
5 printed plan sets mailed to you.
8 Copy Set:
$658.75
8 printed plan sets mailed to you.
PDF Set:
$658.75
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set:
$658.75
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set:
$1147.50
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Single Set:
$467.50
One printed set for bidding purposes only. Not a legal building set for construction.

Foundation

Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse:
$127.50
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets:
$42.50
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
$140.25
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List:
$250.75
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide:
$33.15
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design:
$140.25
Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets:
$51.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
